| Model | GK50 Stainless Steel Diaphragm Pump |
|---|---|
| Max.Working Pressure | 120psi (0.84Mpa, 8.4bar) |
| Max.Flow Rate | 150 gpm (570 lpm) |
| Max.Reciprocating Speed | 145cpm |
| Max. Suction Height(Dry Sucking) | 5m |
| Max.Permitted Grain | 0.24in. (6mm) |
| Max.Air Consumption | 140scfm (70L/s) |
| Air Inlet Size | 1/2 in. |
| Air Outlet Size | 3/4 in. |
| Fluid Inlet Size | 2in. |
| Fluid Outlet Size | 2in. |
| Weight | Stainless steel pump 48kg / Full Stainless steel pump 58kg |
Products Applications
| Industries Involved | Applications |
| Automobile Industry | Polishing emulsions, oils, coolants, automotive priming, oil emulsion paints, varnishes, varnish additives, degreasers / degreasing fluid, paints, etc. |
| Textile Industry | Chemical dyes, resins, glues, etc. |
*Please contact our sales service at sales@gk-supply.com for more details about products applications.
Product Advantages
GK 2 Inches Stainless Steel / Full Stainless Steel Diaphragm Pump which work pressure also higher.
It is suitable for many different acidic substance like three major acids, sulfuric acid, hydrochloric acid, nitric acid, and phosphoric acid, organic acids,and etc.
We most suggest use sea shipping for shipment if you select this pump.
